22. Insert the edge of the paper under the rollers of the paper feeding slit, rotate the paper
roll until the edge of the paper is pulled in automatically to the inside of the machine.
If you insert the paper correctly, the edge of the paper is pulled in to the inside of the machine and
the beeper sounds.
CPT031
1
1
1. Roller
23. Replace the bars of the output basket.
CPT025
1
2
1
2
After pushing the bar that is in front of Paper Input Location 2 into the machine (action in the
illustration), lift the bar of the output basket up and hook it in front of the paper roll (action in the
illustration).
24. Lower the paper input location cover.
CPT038
Loading Paper into the Paper Input Location
115
