Ricoh Pro C5110S - Finishing Position Adjustment

Setting Items Max. Value Min. Value Step Unit
[Adjust Paper Curl Correction Level] 0.5 -0.3 0.1 mm
Finishing Position Adjustment
88: [Adjust Z-fold Position 1]
Adjust the width of the bottom end segment (S) of Z- folded sheets when using the multi-folding unit.
Press [+] to increase (S) and [−] to reduce it.
The mark indicates the leading edge (relative to the paper feed direction), and the mark indicates
the trailing edge.
CEZ001
L
S
Paper feed direction
Setting Items Max. Value Min. Value Step Unit
[Adjust Z-fold Position 1] 4.0 -4.0 0.2 mm
89: [Adjust Z-fold Position 2]
Adjust the overall fold size (L) of Z- folded sheets when using the multi-folding unit.
Press [+] to increase (L) and [−] to reduce it.
The mark indicates the leading edge (relative to the paper feed direction), and the mark indicates
the trailing edge.
4. Details of Menu Items in Advanced Settings
112
