1.SC Codes
61
SC No.
Level
Error Name/Error Condition/Major Cause/Solution
7. Used Toner Transport Motor connector disconnected or harness broken
8. IOB defective
1. Replace waste toner bottle
2. Clean with air, replace parts
3. Check harness connection, replace harness
4. Remove toner, clean bearings, replace defective parts
5. Replace defective parts
6. Replace IOB.
SC No.
Level
Error Name/Error Condition/Major Cause/Solution
SC488-
00
D
Machine Waste Toner Lock Detection Error
The IOB detects the signal frequency of the unit's waste toner and the engine
software samples it at a frequency of 200ms. SC lights if the waste toner lock
detection is abnormal 10 times in a row.
 Physical obstruction is blocking waste toner transport path
 Machine waste toner motor defective
 Used Toner Transport Motor Sensor defective
 Harness broken
 Connection fault
 Physical obstruction is blocking waste toner transport path: Replace or clean
the waste toner transport section.
 Used Toner Transport Motor Sensor defective or harness broken: Replace
parts.
 Connection fault: Reconnect it.
SC No.
Level
Error Name/Error Condition/Major Cause/Solution
SC497-
00
C
Temperature/Humidity Sensor Error (PCU)
One of the following occurred.
 The temperature sensor output was less than 0.5V or more than 2.8V for
three seconds (one second x 3), indicating a problem with the temperature
sensor.
 The humidity sensor output was more than 2.4V for three seconds (one
second x 3), indicating a problem with the humidity sensor.
Details:
Detection is repeated after power off/on.
If either of temperature/humidity sensors works correctly, the working sensor will
be used even after the SC is issued.
The machine continues working with the assumption that the temperature is 23
