Proof Tray Exit Sensor
1. Small upper cover (* "Exterior Cover")
2. Proof tray exit sensor bracket [A] ( x1)
3. Proof tray exit sensor [B] ( x1)
Upper Tray Height Sensors 1, 2
1. Small upper cover, upper cover (* "Exterior Cover")
2. Upper tray paper height sensor bracket [A] ( x1)
3. Upper tray paper height sensor [B] – staple mode (S08) ( x1)
