Fold Unit
Fold Unit
1. Remove the back cover (* "Exterior Covers").
2. Open the front door.
The stapler unit is heavy.
3. Ground cable [A] ( x1)
4. Harness [B] ( x6, x6)
5. Stapler unit [C] ( x4)
1. Replacement and Adjustment
16
1
