Junction Gates
The positions of the proof tray and staple tray junction gates determine the direction of paper feed after
paper enters the finisher.
Proof Mode
Proof tray junction gate [A] opens. Staple tray junction gate [B] remains closed.
The proof tray junction gate directs paper to the proof tray above.
