Rigol DHO900 Series User Manual

Figure 10.13 Track Measurement (after Horizontal Expansion)
Disable the Cursor Measurement Function
When cursor measurement is enabled, you can disable it in the following ways:
• In the Cursors menu, click or tap the Remove button to disable cursor
measurements.
• In the "Result" bar at the right side of the screen, click or tap the "Cursors" label
and then click or tap
Remove in the pop-up window.
• In the "Result" bar at the right side of the screen, drag the "Cursors" label to the
right to simply disable cursor measurements.
• Press the front-panel
key to disable cursor measurements.
10.3.3 XY Mode
In the Cursors menu, click or tap XY for the Mode item to enable the XY cursor
measurement function. The measurement results are displayed in the "Result" bar at
the right section of the screen.
Figure 10.14 XY Mode Setting Menu
Measurements
DHO900 User Guide
154
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
