4.4.1 Front Panel Overview

Figure 4.10 Front Panel

1. 7'' Capacitive Touch Screen

Displays the waveforms, menu labels, and parameter settings, system state,

prompt messages, and other information.

2. Multipurpose Knobs

- Non-menu operation:

When not operating on the menu, you can rotate the knob 1 to adjust the

waveform brightness. When a cursor, decoding, Math waveform, or reference

waveform is added on the screen, you can rotate the multipurpose knob to

Quick Start
