Content Conventions in this Manual

DHO900 series digital oscilloscope includes the following models. Unless otherwise

specified, this manual takes DHO924S as an example to illustrate the operation

methods of DHO900 series.

Model Max. Analog Bandwidth No. of Analog Channels

DHO914 125 MHz 4

DHO914S 125 MHz 4

DHO924 250 MHz 4

DHO924S 250 MHz 4
