RIGOL
5-4 © 2008 RIGOL Technologies, Inc.
User’s Guide for DS1000B Series
Trigger
Trigger Sensitivity
0.1div-1.0div (adjustable)
Trigger Level Range
Internal
±6 divisions from center of screen
EXT
±0.6V
EXT/5
±3V
Trigger Level Accuracy
(typical) applicable for
the signal of rising and
falling time
≥20ns
Internal
±(0.3div × V/div)(±4 divisions from
center of screen)
EXT
±(6% of setting + 40 mV)
EXT/5
±(6% of setting + 200 mV)
Trigger Offset
Normal mode: pre-trigger(storage depth/(2×sampling)
rate), delayed trigger 1s
Slow Scan mode: pre-trigger 6div, delayed trigger 6div
Trigger Holdoff range
100ns~1.5s
HF Rejection
100kHz ±20%
LF Rejection
10kHz ±20%
Set Level to 50%
(t
ypical)
Input signal frequency ≥50Hz
Edge Trigger
Edge trigger slope
Rising, Falling, Rising + Falling
Pulse Trigger
Trigger condition
(˚, ˘, =) Positive pulse, (˚, ˘, =) negative pulse
Pulse Width range
20ns ~10s
Video Trigger
Video standard &
line frequency
Support standard NTSC, PAL and SECAM broadcast
systems. Line number
range: 1~525 (NTSC) and 1~625
(PAL/SECAM)
Pattern Trigger
Pattern setup
H
, L, X, ,
Alternate Trigger
Trigger on CH1,
CH2
, CH3, CH4
Edge, Pulse, Video
Measurements
Cursor
Manual
Voltage difference between cursors (∆V)
Time difference between cursors (∆T)
