User’s Guide for DS1000B Series
5-5
Reciprocal of ∆T in Hertz (1/∆T)
Track
Voltage value for Y-axis waveform
Time value for X-axis waveform
Auto
Cursors are visible for Automatic Measurement
Auto Measure
Vpp, Vamp, Vmax, Vmin, Vtop, Vbase, Vavg, Vrms, Overshoot,
Preshoot, Freq, Period, Rise Time, Fall Time, +Width,
-Width,
+Duty,
-Duty, Delay AėB , Delay AėB ˈPhase AėB ,Phase A
ėB
[1] Half channel indicates selecting one of the channels in CH1 and CH2, or in CH3
and CH4.
[2] This is the highest specification, the specific specifications are as follows:
DS1202/4B: 50GSa/s
DS1102/4B: 25GSa/s
DS1062/4B: 10GSa/s

Rigol DS1102/4B Specifications

General

Brand	Rigol
Model	DS1102/4B
Category	Test Equipment
Language	English
