User’s Guide for DS1000B Series
2-5
Figure 2-4
Waveform display
Press CH1ėCouplingėGND, to set “GND” coupling, it disconnects the input signal.
The screen displays as Figure 2-5:
Figure 2-5
Screen display
GND coupling
Status symbol
GND coupling
Setup
AC coupling
S
etup
AC coupling
Status symbol
