Chapter 5 To Trigger the Oscilloscope RIGOL
DS8000-R User Guide 5-33
Parity:
Used to verify whether data are properly transmitted. Click More → Parity to select
the desired parity. The available parity include "None", "Even", and "Odd".
Polarity:
Click Polarity continuously to select the polarity of data transmission. It can be set
to "Pos" or "Neg" .
Baud Rate:
Set the baud rate of data transmission (i.g. specifies a clock frequency). The
following setting methods are available for baud rate:
⚫ Click Baud Rate, then set the user-defined baud rate with the displayed
numeric keypad or by scrolling with the mouse.
⚫ Click Baud Rate, then select the preset baud rate from the available options.
The available baud rates include 50 bps, 75 bps, 110 bps, 134 bps, 150 bps, 300
bps, and etc.
Trigger Mode:
For details, refer to descriptions in "Trigger Mode".
Trigger Parameter Setting:
For details, refer to descriptions in "Noise Rejection".
Trigger Level:
Refer to "Trigger Level". The current trigger level value is displayed at the
upper-right corner of the screen.
