Color Setting
DS8000-R series oscilloscope provides five colors (gray, green, blue, red, and orange)
to mark the reference waveforms of different channels in order to distinguish the
reference waveforms of different reference waveform channels.
Click Color to select the color of the reference waveform of the channel. The GND
icon and the label at the left side of the waveform of the currently selected channel
will be filled with the specified color. For example, and .
Label Setting
Click More → Label to enter the label setting menu. You can use the built-in label in
the library or manually input a label. Three input methods are available for you to
input a label name, including Chinese, English, and Traditional Chinese.
âš« Click Display continuously to enable or disable the display of the reference
waveform label. If it is enabled, the label will be displayed at the left side of the
waveform. If the current channel is REFn (n=1,2, …10), then the default label of
the reference waveform is REFn (n=1, 2, …10).
âš« Click Library to select the preset label. The available preset labels include
Default, ACK, ADDR, BIT, CLK, and etc.
âš« Click Label, and the label editing interface is automatically displayed. You can
input the label manually. For the label editing methods, refer to descriptions in
"Channel Label".
To Export to Internal or External Memory
You can also save the current reference waveform to the internal memory or external
USB storage device. The file format of the reference waveform is ".ref", ".bin", or
".csv".
Click More → Export to enter the reference waveform file saving interface. Please
refer to descriptions in "Store and Load" to save the reference waveform to the
internal or external memory. Only when the reference waveform is saved, can this
export function be valid.
Note: DS8000-R series oscilloscope only supports the flash memory USB storage
device of FAT32 format.
