Chapter 6 Operations and Measurements RIGOL
DS8000-R User Guide 6-35
Remove the Measurement Result
This oscilloscope allows you to remove the measurement results of the parameters.
Click Measure → Remove to enter the "Remove" sub-menu.
⚫ Click Remove to remove the last added measurement item. Note that clicking
this key one time can only remove one measurement item. When you remove a
measurement item, the measurement result of the last added item at the
bottom of the screen will be removed.
⚫ Click Remove All to remove all the displayed measurement items.
⚫ Click Indicator to enable or disable the indicator.
Besides, you can also click Measure → Add → Remove to enter the "Remove"
sub-menu.
Statistical Function
Performs statistics and displays the measurement results (Cur, Avg, Max, Min, Dev,
and Cnt) of at most 10 items, as shown in the figure below.
Tip
⚫ Modifying the threshold will affect the measurement results of
the time, delay and phase parameters.
⚫ If you select "Manual" under Amp Method, the measurement
results of other parameters may be affected.
⚫ "Histogram" and "Max-Min" are the internal measurement
algorithm for the oscilloscope. The "Histogram" method here is
different from the Histogram function of the oscilloscope.
Tip
If the "Remove" sub-menu is not displayed in the current menu, when you select
a certain measurement item, the system will automatically enter the "Remove"
sub-menu.
