Chapter 1 Quick Start RIGOL
DS8000-R User Guide 1-17
⚫ Displays the status of CH3.
⚫ Displays the vertical scale of CH3. That is, the voltage value per grid of CH3
in the vertical axis.
⚫ Displays the offset of CH3, i.g. the vertical offset of CH3 waveform.
⚫ Different labels will be displayed according to the current channel setting.
For example, if you select "DC" for channel coupling, is displayed; if you
enable the bandwidth limit, is displayed; if you select "50 Ω" for
impedance, is displayed.
19. CH2 Status Label
⚫ Displays the status of CH2.
⚫ Displays the vertical scale of CH2. That is, the voltage value per grid of CH2
in the vertical axis.
⚫ Displays the offset of CH2, i.g. the vertical offset of CH2 waveform.
⚫ Different labels will be displayed according to the current channel setting.
For example, if you select "DC" for channel coupling, is displayed; if you
enable the bandwidth limit, is displayed; if you select "50 Ω" for
impedance, is displayed.
20. CH1 Status Label
⚫ Displays the status of CH1.
⚫ Displays the vertical scale of CH1. That is, the voltage value per grid of CH1
in the vertical axis.
⚫ Displays the offset of CH1, i.g. the vertical offset of CH1 waveform.
⚫ Different labels will be displayed according to the current channel setting.
For example, if you select "DC" for channel coupling, is displayed; if you
enable the bandwidth limit, is displayed; if you select "50 Ω" for
impedance, is displayed.
21. Function Navigation
Click the function navigation icon at the lower-left corner of the externally
connected screen to open the function navigation.
Common Operation
Click Operation
⚫ Click the menu displayed on the externally connected screen to operate on the
menu.
⚫ Click the function navigation icon at the lower-left corner of the externally
connected screen to open the function navigation.
⚫ Click the displayed numeric keypad to set the parameters.
⚫ Click the virtual keypad to set the label name, the filename, and other character
strings.
