Chapter 17 Function/Arbitrary Waveform Generator (Option) RIGOL
DS8000-R User Guide 17-5
To Output Noise
Click Wave to select "Noise". At this time, you can set the amplitude/high level,
offset/low level, and impedance of the noise signal. For detailed setting methods,
refer to relevant contents in "To Output Sine".
Sinc
Click Wave to select "Sinc". You can set the parameters for the Sinc waveform (as
shown in the figure below). For setting methods, refer to descriptions in "To Output
Sine".
Figure 17-3 Sinc
Exp.Rise
Click Wave to select "Exp.Rise ". At this time, you can set the parameters for the
Exp.Rise waveform (as shown in the figure below). For setting methods, refer to
descriptions in "To Output Sine".
Figure 17-4 Exp.Rise
