Chapter 17 Function/Arbitrary Waveform Generator (Option) RIGOL
DS8000-R User Guide 17-17
2. Set the Number of Cycles
When the burst type is set to "N Cycle", you need to set the number of cycles.
Click Cycles, then use the pop-up numeric keypad or scroll with the mouse to
set the number of cycles. For the Infinite burst type, the Cycles menu is
disabled and grayed out.
3. Set the Burst Delay
Burst delay indicates the time from when receiving the trigger signal to starting
to output N Cycle of bursts or Infinite burst.
Click Delay, then use the pop-up numeric keypad or scroll with the mouse to set
the desired delay time. The range of the delay time is related to the burst cycles,
waveform frequency, and burst period.
4. Burst Setting
Click Settings to enter the burst setting menu.
⚫ Set the trigger source
The trigger sources of the burst can be Internal or Manual. When the
Function/Arbitrary Waveform Generator receives a trigger signal, a burst
output is generated, and then it waits for another trigger signal.
Click Trig Source to select the desired trigger source. The available trigger
sources include Internal and Manual. For the Infinite burst type, the Trig
Source menu is disabled and grayed out. You can only initiate an trigger
manually.
➢ Internal: The Function/Arbitrary Waveform Generator outputs
continuous N cycle bursts.
➢ Manual: When you click Manual Trig for one time, one burst output is
immediately launched for the channel. For the Infinite burst type, the
Cycles menu is disabled and grayed out.
⚫ Set the burst period
It is defined as the time from the beginning of one burst to that of another
burst.
Click Burst Period, then use the pop-up numeric keypad or scroll with the
mouse to set the desired burst period. Its available range is from 1 us to
500 s. By default, it is 10 ms.
