Display Diagnosc Codes
To display diagnosc codes, follow the steps below.
1. Press and hold the Domesc Hot Water buon for
two seconds, and then the (Up) buon (hold
both buons at the same me).
2. The last nine maintenance codes display and ash
one aer the other.
3. To exit diagnosc codes and return the boiler to
normal operaon, press and hold the Domesc
Hot Water buon for two seconds, and then the
(Up) buon (hold both buons at the same me).
100
Air Supply or Exhaust Blockage/Condensate
Trap is Full
• Fan current inial check error.
• Ensure condensate line and trap is not
blocked.
• Ensure internal air lter is clean with no
obstrucons.
• Ensure high altude seng is set properly
(See High Altude Seng).
• Ensure combuson air and exhaust vents
are not blocked and the approved venng
materials are being used.
• Ensure either the exhaust ring or intake
cap is removed properly.
• Ensure vent length is within limits.
• Check fan for debris and ensure wheel
turns freely.
• Verify fan check valve is not stuck
between fan casing and burner body.
110 No Ignion (Unit Not Turning On)
• Ignion Error.
• Check that the gas is turned on at the
boiler, gas meter, and/or propane
cylinder.
• If the unit is installed in a propane system,
ensure that gas is in the tank.
• Bleed all air from the gas lines.
• Check the ground wire for the PC Board.
• Ensure the ame rod wire is connected.
• Ensure the igniter is operaonal.*
• Ensure the venng is installed in
accordance to this manual.
• Check that the surface of the electrode
and ame rod are clean.
• Check gas solenoid valves for open or
short circuits.*
• Verify gas orice installed is correct for the
gas system the unit is installed in.
• Check ame rod voltage to ground during
ignion.
120
Flame Failure
• Boiler has ame failure.
• Check that the gas is turned on at the
boiler, gas meter, and/or propane
cylinder.
• If the unit is installed in a propane system,
ensure that gas is in the tank.
• Ensure the venng is installed in
accordance to this manual.
• Ensure the ame rod wire is connected.
• Ensure the gas type and inlet gas pressure
are correct.
• Bleed all air from the gas lines.
• Check the ground wire to the PC Board.
• Check ame rod voltage to ground during
ignion.
* See “Electrical
Diagnoscs” on
Technical Data Sheet
located on inside front
cover of boiler.
Some of the checks below
should be performed by a
licensed professional. Consumers should never
aempt any acon that they are not qualied to
perform.
Reset Diagnosc Codes
To reset diagnosc codes, either the Central Heang or
Domesc Hot Water buon on the control panel will
be blinking. Press the buon to reset the code.
Diagnosc Codes
IMPORTANT
• Diagnosc codes that occur during DHW
operaon may be able to reset by turning o the
faucet.
• Some diagnosc codes may not reset by pressing
the CH or DHW buons. If this is the case,
contact your service provider for troubleshoong
assistance.
1:100
e:100
