Rinnai I-Series Condensing Boiler Combi Manual 79
* Refer to the Technical Data Sheet located on the inside front cover of the boiler for addional
informaon.
# DATA UNIT
01
Water Pressure PSI/bar
02
Water Flow Rate x0.1 GPM/LPM
03
Supply Temperature °F/°C
04
Return Temperature °F/°C
05
Freeze Protecon Temperature °F/°C
06
Exhaust Temperature °F/°C
07
Outgoing Temperature °F/°C
08
Inlet Temperature °F/°C
10
Heat Exchanger Outlet Temperature °F/°C
11
Fan Frequency Hz
13
Water Flow Control Posion 0=Mid, 1=Open, 2=Closed
14
Bypass Flow Control Posion Degrees of Opening
15
3-Way Valve Control Posion 0=Mid, 1=DHW, 2=CH
16
3-Way Valve Control Cycles x100
17
Venturi Posion 0=Closed, 1=Open
18
Venturi Cycles x100
20
Pump Cycles x100
21
Pump Hours x10 Hours
22
Pump for Boiler 0=OFF, 1=ON
23
Pump for System (Pump 1) 0=OFF, 1=ON
24
Pump for System (Pump 2) 0=OFF, 1=ON
31
Outdoor Temperature °F/°C
32
Addional Controllers Connected *
40
Energizaon Hours x100 Hours
41
Combuson Hours x10 Hours
42
Combuson Cycles x100
43
Combuson Hours (DHW) x10 Hours
44
Combuson Cycles (DHW) x100
45
Commissioning Cycles x1
Unit of measurement (°F/°C, PSI/bar, and GPM/LPM) will vary depending on unit of
measure selecon.
IMPORTANT
