114 Rinnai I-Series Condensing Boiler Combi Manual
Legend:
Refer to the legend below for the system applicaons shown in this secon.
IMPORTANT
Primary/secondary piping is necessary in the following applicaons:
When using external pumps
Large zoned systems
High ow applicaons
Systems with high dierenal pressures
Systems with high pressure drops
For pressure curve informaon, refer to the following secons in the Appendix.
14.8 CH Pressure Drop and Flow Curve
14.9 DHW Pressure Drop and Flow Curve
This picture illustrates a suggested
arrangement. Some of the ngs
are oponal.
