Following is a list of vent components and terminaons for Direct Vent installaons (concentric and twin pipe).
Install the correct venng for your model according to the venng manufacturer’s instrucons and the guidelines
below. The informaon below is correct at me of publicaon and is subject to change without noce. Contact the
vent manufacturer for quesons related to the vent system, products, part numbers and instrucons.
Manufacturer Phone Web Site
Ubbink 800-621-9419 www.rinnai.us
Centrotherm 877-434-3432 www.centrotherm.us.com
Heat-Fab 800-772-0739 www.heaab.com
Metal Fab 800-835-2830 www.metal-fabinc.com
IPEX U.S.: 800-463-9572 Canada: 866-473-9462 www.ipexamerica.com, www.ipexinc.com
DuraVent 800-835-4429 www.duravent.com
Royal 800-232-5690 www.royalbuildingproducts.com
ECCO Manufacturing 877-955-4805 www.eccomfg.com
DiversiTech 800-995-2222 www.diversitech.com
Z-FLEX 603-669-5136 www.z-ex.com
2 in./4 in. CONCENTRIC VENT TERMINATIONS
229011NPP
229012NPP
229013NPP
2/4 Condensing Horizontal Terminaon Kit 8.7 in.
2/4 Condensing Horizontal Terminaon Kit 12 in.
2/4 Condensing Horizontal Terminaon Kit 21 in.
5
224356NPP 2/4 Condensing Roof Discharge Terminaon
20 in. above roof
5
710202NPP 2/4 Condensing 90 Degree Diverter Nose
(Use with Wall Terminal)
5
710215NPP 2/4 Condensing 45 Degree Diverter Nose
(Use with Wall Terminal)
5
196005, 197040 FGV Concentric Vent Kit (16 in. length)
20
196105, 197033 FGV Concentric Vent Kit (28 in. length)
20
196125 FGV Concentric Vent Kit (40 in. length)
20
UBBINK
IPEX
Manufacturer
Manufacturer
Part Number
Product
Descripon
Diagram
Horizontal
Vercal
Equivalent Length
()
2 in./4 in. CONCENTRIC VENT TERMINATIONS
