Rinnai 53 Multi Split Type AC
COMMISSIONING
Commissioning Check List
Installer to please complete all sections of this form.
System Information
Model
(Outdoor Unit)
Serial No.
(Outdoor Unit)
Model
(Indoor Unit)
Serial No.
(Indoor Unit)
Model Serial No.
Installed by / Date
Pre Start-Up
(Please tick boxes below as each item is completed).
Verify that all packaging materials have been removed from the unit.
Remove all shipping hold down bolts and brackets, as per installation instructions.
Check that condensate connection is installed, as per installation instructions.
Check all electrical connections and terminals for tightness.
Check that indoor return air lter is clean and in place.
Verify that unit installation is level.
Check fans for alignment and noise
Operation Characteristics
(Please record the following data after at least 20 minutes running time).
Suction Pressure kPa
Suction Line Temperature °C
Discharge Pressure kPa
Liquid Line Temperature °C
Superheat K
Sub-Cooling K
Compressor Amps (L1) A
Compressor Amps (L2 for 3 phase) A
Compressor Amps (L3 for 3 phase) A
Indoor Coil Air On (Return) Temperature °C DB
Indoor Coil Air On (Supply) Temperature °C DB
Outdoor Air Temperature (Ambient) °C DB
Length of Liquid Line m
Length of Suction Line m
Liquid Line Diameter mm
Suction Line Diameter mm
Extra refrigerant quantity charged (if any) kg
Supply Voltage V
Actual Voltage V
