TECHNICAL SPECIFICATIONS
WALL MOUNTED SPLIT SYSTEM HINRP20M HINRP26M HINRP35M HINRP50M HINRP60M HINRP70M
Power Supply V-Ph-Hz 220~240-1-50
Cooling
Rated Capacity kW 2.0 2.6 3.5 5.0 6.0 7.0
Rated Input Power W 415 530 820 1300 1800 1950
Rated Input Current A 1.8 2.5 3.8 5.8 8.0 8.7
Heating
Rated Capacity kW 2.2 2.7 4.0 5.2 6.2 7.5
Rated Input Power W 460 920 920 1350 1700 1950
Rated Input Current A 2 2.5 5 6 7.5 8.7
Airow (Turbo/ Hi / Med / Lo / Min) L/s
153 / 128 / 94 /
75 / 47
175 / 139 / 100 /
83 / 56
183 / 147 / 106 /
86 / 58
264 / 222 / 167 /
139 / 89
264 / 222 / 167 /
139 / 89
382 / 303 /250 /
229 / 147
Sound Pressure (Turbo/ Hi / Med /
Lo / Min) @1.0m
dB(A)
43 / 38 / 31 / 30
/ 25
46 / 39 / 32 / 30
/ 24
46 / 39 / 32 / 30
/ 24
47 / 44 / 38 / 34
/ 28
47 / 44 / 38 / 34
/ 28
57 / 45 / 39 / 33
/ 29
Dimensions
Net (W x D x H)
mm
729 x 200 x 291 802 x 200 x 295 802 x 200 x 295 971 x 228 x 321 971 x 228 x 321 1082 x 234 x 337
Gross (W x D x H) 965 x 282 x 370 1010 x 385 x 312 1010 x 385 x 312 1067 x 312 x 385 1067 x 312 x 385 1205 x 317 x 400
Net / Gross Weight kg 8 /10 8 / 11 8 / 11 11 / 14 11 / 14 13 / 17
Refrigeration Pipe
Size: Liquid / Gas
mm Φ6.35 / Φ9.52 Φ6.35 / Φ9.52 Φ6.35 / Φ9.52 Φ6.35 / Φ12.7 Φ6.35 / Φ12.7 Φ9.52 + Φ15.9
Controller Type Wireless Remote Control
Operating Range
Cooling
°C
16~32
Heating 0~30
Wi-Fi Compatibility Standard
MULTI OUTDOOR UNIT MON3H07B MON4H09B MON5H11B
Number of Indoor Units Qty 3 4 5
Power Supply (To Outdoor Unit) V-Ph-Hz 220~240-1-50
Cooling
Rated Capacity (Range) kW 7. 5 (1.7 – 9.8) 9.15 (1.7 – 11.5) 12.0 (1.7 – 12.3)
Rated Input Power kW 1.98 2.38 3.42
Rated Input Current A 8.90 10.09 15.65
AEER W/W 3.79 3.84 3.51
Heating
Rated Capacity kW 7.4 (1.8 – 9.6) 9.6 (1.8 – 12.0) 12.5 (1.8 – 12.9)
Rated Input Power kW 1.59 2.25 3.10
Rated Input Current A 7.28 10.30 14.19
ACOP W/W 3.80 3.86 3.43
Maximum Input Current A 17.5 19.0 19.0
Compressor Type Inverter Twin Rotary
Sound Power Level dB(A) 65 68 72
Dimensions
Net (W x D x H)
mm
890 x 342 x 673 946 x 410 x 810 946 x 410 x 810
Gross (W x D x H) 1030 x 438 x 750 1090 x 500 x 885 1090 x 500 x 885
Net / Gross Weight kg 48 / 51 66 / 72 76 / 82
Refrigerant Type R32
Refrigerant Piping
Connection Size: Liquid Line
mm
3 x Φ6.35 4 x Φ6.35 5 x Φ6.35
Connection Size: Gas 3x Φ9.52 3 x Φ9.52 + 1 x Φ12.7 4 x Φ9.52 + 1 x Φ12.7
Maximum Total System Pipe Length
m
60 80 80
Pre-Charged Length 30 40 50
Maximum Length Per Indoor Unit 30 35 35
Maximum Vertical Separation Outdoor
Unit ABOVE Indoor Unit
10 10 10
Maximum Vertical Separation Outdoor
Unit BELOW Indoor Unit
15 15 15
Maximum Height Difference Between
Indoor Units
10 10 10
24°C Ambient
Temperature Limits
Cooling
°C
-15~50
Heating -25~30
