TECHNICAL SPECIFICATIONS
SLIM DUCTED DINSD26MB DINSD35MB DINSD50MB DINSD70MB
Power Supply V-Ph-Hz 220~240-1-50
Cooling
Rated Capacity kW 2.6 3.5 5.2 7.1
Rated Input Power W 180 185 200 200
Rated Input Current A 1.1 1.1 1.3 1.3
Heating
Rated Capacity kW 2.9 3.8 5.5 7.3
Rated Input Power W 180 185 200 200
Rated Input Current A 1.1 1.1 1.3 1.3
Airow (Hi / Med / Lo) L/s 500 / 340 / 230 500 / 340 / 230 600 / 480 / 300 880 / 650 / 350
Maximum External Static Pressure (Hi) Pa 60 60 100 160
Sound Pressure (Hi / Med / Lo) @1.0m dB(A) 40 / 34 / 27 40 / 34 / 27 40 / 34 / 27 41 / 38 / 33
Dimensions
Net (W x D x H)
mm
700 x 506 x 200 700 x 506 x 200 880 x 674 x 210 1100 x 774 x 249
Gross (W x D x H) 860 x 540 x 285 860 x 540 x 285 1070 x 725 x 280 1305 x 805 x 315
Net / Gross Weight kg 18 / 22 18 / 22 24 / 29 32 / 39
Supply Air Duct Connection (W x H)
mm
537 x 152 537 x 152 706 x 136 926 x 175
Return Air Duct Connection (W x H) 599 x 186 599 x 186 782 x 190 1001 x 228
Refrigeration Pipe Size: Liquid / Gas Φ6.35 / Φ9.52 Φ6.35 / Φ9.52 Φ6.35 / Φ9.52 Φ9.52 /Φ15.9
Condensate Drain Pump Connection mm ODΦ25mm
Controller Type Wired Controller - 12m Cable
Operating Range
Cooling
°C
17~32
Heating 0~30
Wi-Fi Compatibility Optional
COMPACT CASSETTE CIN20RMB CIN26RMB CIN35RMB CIN50RMB
Fascia Panel Model No. CINFASM
Power Supply V-Ph-Hz 220~240-1-50
Cooling
Rated Capacity kW 2.1 2.6 3.5 5.2
Rated Input Power W 40 40 40 102
Rated Input Current A 0.18 0.18 0.18 0.44
Heating
Rated Capacity kW 2.3 2.9 4.1 5.4
Rated Input Power W 40 40 40 102
Rated Input Current A 0.18 0.18 0.18 0.44
Airow (Hi / Med / Lo) L/s 580 / 500 / 450 580 / 500 / 450 569 / 485 / 389 680 / 584 / 479
Sound Pressure (Hi / Med / Lo) @1.0m dB(A) 38 / 33 / 29 38 / 33 / 29 41 / 37 / 34 44 / 42 / 41
Dimensions
Net - Body (W x D x H)
mm
570 x 570 x 260 570 x 570 x 260 570 x 570 x 260 570 x 570 x 260
Gross - Body (W x D x H) 662 x 662 x 317 662 x 662 x 317 662 x 662 x 317 662 x 662 x 317
Net - Fascia (W x D x H) 650 x 650 x 60 650 x 650 x 60 650 x 650 x 60 650 x 650 x 60
Gross - Fascia (W x D x H) 700 x 700 x 110 700 x 700 x 110 700 x 700 x 110 700 x 700 x 110
Net / Gross Weight - Body
kg
14 / 17 14 / 17 16 / 20 16 / 21
Net / Gross Weight - Fascia 2 / 4 2 / 4 2 / 4 2 / 4
Refrigeration Pipe Size: Liquid / Gas mm Φ6.35 / Φ9.52 Φ6.35 / Φ9.52 Φ6.35 / Φ9.52 Φ6.35 / Φ12.7
Condensate Drain Pump Connection mm ODΦ25mm
Controller Type Wireless Remote Control
Operating Range
Cooling
°C
17~32
Heating 0~30
Wi-Fi Compatibility Optional
Capacities tested in accordance with AS/NZS 3823.3, with 5m interconnecting length for all attached Indoor Units. With our policy of continuous improvement, we reserve
the right to change, or discontinue at any time, specications or designs without notice.
05 September 2022
