Rinstrum 300 Series - Programmable Printing - K35; How to Set Custom Print Strings Using View 300; Tokens

Reference Manual V1.19 Software Versions 4.xx
Page 50 003R-682-119
12. Programmable Printing – K35*
Two user determined print strings with tokens can be programmed into an instrument using
View300.
12.1. How to set custom print strings using View 300
- Connect instrument to PC with View300
- Open full session - select instrument menu/ select custom print format.
- Edit the two custom print strings
- Hex values (such as tokens) must be preceded with a “\”.
- All hex values less than 7F
H
will be interpreted as ASCII characters.
- Alternatively, you can use the protocols and techniques described in the “Communications
Manual” to enter custom strings.
12.2. Tokens
Gross Weight
CF
H
Current gross weight
Net Weight
DO
H
Current net weight
Tare Weight
D8
H
Current tare weight
Display Weight
D9
H
Current display weight
Count
F0
H
Current count (if counting is turned on)
ID
DA
H
Current print ID
Time
C0
H
Current time
Date
BF
H
Current date
Total Weight
DB
H
Total of printed Display Weight since last summary
print (long press).
Total Count
DD
H
Total number of pieces in Total Weight (if counting
turned on)
Items
DC
H
Number of items printed since last summary print.
Standard Print (short press)
7F
H
Standard print
Standard Print (long press)
8F
H
Standard summary
Streaming Register Raw
F9
H
Raw value of streaming register(s)
Weights as 5 chars
95
H
Weights as 5 chars, decrementing to 3 with wrapping
(5,4,3,5…)
Weights as 6 chars
96
H
Weights as 6 chars
Weights as 7 chars
97
H
Weights as 7 chars
Weights as 8 chars
98
H
Weights as 8 chars
Weights as 9 chars
99
H
Weights as 9 chars
Weights as 10 chars
9A
H
Weights as 10 chars
No sign chars
9B
H
No sign chars
Sign is positive ‘ ‘, negative ‘-‘
9C
H
Sign is positive ‘ ‘, negative ‘-‘
Sign is positive ‘0’, negative ‘-‘
9D
H
Sign is positive ‘0’, negative ‘-‘
Sign is positive ‘+’, negative ‘-‘
9E
H
Sign is positive ‘+’, negative ‘-‘
No decimal point
9F
H
No decimal point
