12.3. Using Tokens Example
Custom Print String definition:
Resulting Print Out:
\D9 at \C0 on \BF\0D\0A
523 kg G at 09:18 on 10/08/2006<CR><LF>
12.4. Clear Custom Print Strings
The menu selection FACTRY:DEFLT is used to clear the programmed printing and revert to the
standard printing format.
12.5. Printing Custom Print Strings
Short Press <PRINT> key: to print the programmed print string up to 200 characters including
tokens.
Long Press <PRINT> key: to print the programmed summary print string up to 99 characters
including tokens.
12.6. Master Serial Output
In Master mode, the instrument sends out the entire contents of the LCD at the selected auto output
speed. This is essentially the same as AUTO output but the format of the output string is designed to
allow a remote display to exactly copy the contents of the LCD including all the annunciators and
user prompts, etc.
12.7. Auto Output Speed
There are four speeds to choose from: 10, 5, 2 & 1Hz. If using a remote input auto output speed
must be set to 10Hz.
12.8. Print Interlock
The print interlock (I.LOCK) sets the type of printing interlock to be used. Printing is enabled every
time the scale becomes stable when MOTION is selected. Or printing is enabled after the scale has
returned to zero and is stable when RET.Z is used.
12.9. Unit Switching
Units will be restored to their previous state after printing is complete. It is not recommended to use
the unit switching tokens (\D2 to \D6) in an auto string, as the display will flicker between units
constantly.
