Reference Manual V1.19 Software Versions 4.xx
003R-682-119 Page 7
2. Specifications
Up to 60,000 divisions, minimum of 0.25V/division
0.1mV/V to 3.0mV/V full scale
5 V for up to 4 x 350 or 8 x 700-ohm load cells (4-wire or 6-wire plus shield)
Max total load cell resistance: 3,500Ω (4x350Ω Nontrade 8x350Ω)
24bit Sigma Delta with 8,388,608 internal counts
20 updates/second
Temperature: –10° to +50C ambient (14° to 122° F)
Humidity: <90% non-condensing
LED Backlit LCD with six 20mm (0.8") high digits with units and annunciators
Full digital with visual prompting in plain messages
Sliding window average from 0.1 to 4.0 s
Selectable from ± 2% to ± 100% Full Scale
7 to 24VDC, 4.8, 9.6,12 and 24V batteries (2.5 VA max)
ON/OFF key with memory feature
AC Plug pack: 110/240VAC 50/60Hz in 12VDC
1.5A out
AC Power supply: 110/240VAC 50/60Hz in
12VDC 1.2A out
12V battery pack (rechargeable NiMH)
12V battery pack (rechargeable NiMH)
Stainless Steel Flush Mount
Basic Indicator: 0.34kg (12oz)
Basic Indicator: 0.49kg (17oz)
Optical Data Communications
Magnetically coupled infra-red communications
Conversion cables available for RS232 or USB
RS232 automatic transmit, network or printer outputs.
Transmission rate: 2400, 4800, 9600, 19200 or 38400 baud
Unit switching, counting, manual hold, peak
hold, totalising, high resolution, auto tare,
display test
Battery Backed Clock Calendar
Battery life 10 years minimum
2 Outputs -
isolated transistor drive outputs (300mA total at 50VDC)
4,000 d @0.8uV/d NMI (S-420), OIML R76
10,000d III/III L NTEP 08-072 A1
