67
Recall Mode
Manual store data when using frequency zoom
The number of data per address is fixed. For spectrum display, it is 102 and for
time waveform display 128 data.
When a frequency zoom ratio of 2 or higher is used, the number of data increases
accordingly, but not all data can be stored. The principle shown below is applied.
Spectrum: 102 data (as shown on display)
Time waveform: leftmost 128 data of data shown on display
Regardless of X axis zoom setting during store, X axis
zoom is set to maximum during recall.
Example: Measurement screen Recall screen
Frequency zoom (ZM × 4) ZM × 4
X axis zoom (ZM × 2) X × 4
Cursor control
1. Press the SETUP (ESC) key to turn off the reverse cursor.
2. Use the keys to move the cursor.
To Next Page
