61
Recall Mode
When recall mode is selected, stored measurement results are displayed, along
with the measurement parameters that were active at the time when the data
were stored.
Recall is carried out for each address individually.
Activating the recall screen
1. Press the SETUP (ESC) key to call up the reverse cursor.
2. Use the keys to move the reverse cursor to the "measurement
state" field.
3. Use the keys to select "RECLL" (RECALL).
Note
When switching from the measurement screen to the
recall screen, key presses are not registered for about
10 seconds after transient store is completed.
Changing the memory address
1. Press the SETUP (ESC) key to activate the reverse cursor.
2. Use the keys to move the cursor to the memory address field.
3. Use the keys to change the address.
