16 WatchOUT DT Installation Manual
Quick Keys Parameter Default
MW Range options [2][0][3][zzz]
[3][1]..[7]
1) Minimum
2) 20%
3) 40%
4) 60%
5) 80%
6) Maximum
7) Trimmer (MW is defined
by the trimmer setting on
the PCB)
Alarm Logic PIR and Microwave
[2][0][3][zzz]
[4]
Determine the detector’s logic of defining an alarm.
PIR and Microwave
[2][0][3][zzz]
[4][1]
Alarm is activated when both PIR and MW channels detect an alarm
(AND Logic)
PIR or Microwave
[2][0][3][zzz]
[4][2]
An alarm is activated when either PIR or MW channels detect an alarm (OR
Logic)
Lens Type Wide Angle
[2][0][3][zzz]
[5]
Defines the actual Lens of the detector
Lens Type Options
[2][0][3][zzz]
[5][1]..[2]
1) Wide Angle 2) Barrier / Long Range
Anti-Mask Enable
[2][0][3][zzz]
[6]
Defines the operation of Anti Masking detection
Anti-Mask Options
[2][0][3][zzz]
[6][1]..[2]
1) Disable 2) Enable (Default)
Arm/Disarm No
[2][0][3][zzz]
[7]
Defines the operation of the LEDs anti masking detections while the detector
is armed
No
[2][0][3][zzz]
[7][1]
AM (Anti masking) is enabled
LEDs behave according to the LEDs parameter definition
Yes
[2][0][3][zzz]
[7][2]
AM (anti masking) is disabled
LEDs are disabled
System Parameters
System: System Control
Quick Keys Parameter Default:
AM=Tamper No [1][2][36]
Used to determine the operation of Anti Masking detection
Yes: Anti mask violation will activate tamper alarm.
No: Anti mask violation will be regarded as trouble event.
VBR=Tamper No [1][2][37]
Used to determine the operation of the vibration detection (applicable to
versions with Vibration sensor installed)
Yes: Vibration detection will activate tamper alarm.
No: Vibration detection will be regarded as trouble event.
