Riso GR 3770 - Page 38

MASTER MAKING SECTION
ADJUSTMENT
GR3770 4 - 4
TPH VOLTAGE SETTING TABLE
RESISTANCE VALUE (Ω) VOLTAGE (V)
1700 ∼ 1713 11.4
1714 ∼ 1743 11.5
1744 ∼ 1774 11.6
1775 ∼ 1804 11.7
1805 ∼ 1835 11.8
1836 ∼ 1866 11.9
1867 ∼ 1897 12.0
1898 ∼ 1929 12.1
1930 ∼ 1961 12.2
1962 ∼ 1993 12.3
1994 ∼ 2026 12.4
2027 ∼ 2058 12.5
2059 ∼ 2091 12.6
2092 ∼ 2124 12.7
2125 ∼ 2158 12.8
2159 ∼ 2192 12.9
2193 ∼ 2226 13.0
2227 ∼ 2260 13.1
2261 ∼ 2294 13.2
2295 ∼ 2300 13.3
