APPENDIX (I)
ADVICE DISPLAYS
GR3770 APX(I)-18
3. SETTING CONFIRMATION MESSAGES
Display Details How to Cancel
CLOSE
FRONT COVER
ADD PAPER
SET DRUM
IN PLACE
INSTALL
PRINT CYLINDER
WRONG-SIZE DRUM (PRINT
CYLINDER) INSTALLED
WRONG-TYPE DRUM (PRINT
CYLINDER) INSTALLED
INSTALL INK
CARTRIDGE
WRONG-TYPE
INK CARTRIDGE
INSTALLED
SET (INSTALL) MASTER
DISPOSAL BOX
CLOSE SCANNER
TABLE
CLOSE ADF COVER
CLOSE MASTER
LOADING UNIT
SET LEAD EDGE OF
MASTER
UNDER
GREEN FILM
Close Front Cover
Displayed to prevent the machine operation:
• If the metal plate is not attached to the Front cover set sensor.
Add Paper
Displayed to interrupt the machine operation:
• If the light path of the Paper detection sensor is open.
Set Drum in Place
Displayed to prevent the machine operation:
• If the actuator of the Drum set switch is not depressed.
Drum Size Error
Displayed to prevent the machine operation:
• If a wrong size drum is set in the machine.
Drum Brand Error
Displayed to prevent the machine operation:
• If a wrong brand drum is set in the machine.
Set Ink Cartridge in Place
Displayed to prevent the machine operation:
• If the actuator of the Ink bottle switch is not depressed.
Ink Cartridge Brand Error
Displayed to prevent the machine operation:
• If a wrong type of ink cartridge is set in the machine.
Set Master Disposal Box in Place
Displayed to prevent the machine operation:
• If the actuator of the Disposal box set switch is not depressed.
Close Scanner Table
Displayed to prevent the machine operation:
• If the safety switch is not pressed by the Scanner table.
Close ADF Unit
Displayed to prevent the machine operation:
• If the actuator of the ADF unit set switch is not depressed.
Close Master Loading Unit
Displayed to prevent the machine operation:
• If the actuator of the Master loading unit switch is not de-
pressed.
Set Leading Edge of Master Under Green Films
Displayed to prevent the machine operation:
• If the Master detection sensor does not detect master material
(the reflected light).
Front cover set sensor ON
Paper detection sensor ON
Drum set SW ON
Ink bottle SW ON
Disposal box set SW ON
Scanner table set SW ON
Interlock SW ON
ADF unit set SW ON
Master loading unit SW
Master detection sensor ON
