APPENDIX (I)
ADVICE DISPLAYS
GR3770APX(I)-17
Display Details How to Cancel
DISPOSAL ERROR
REMOVE DRUM (PRINT
CYLINDER) AND
DISCARD MASTER
⇓
TO RETURN OPERATION
PRESS START KEY
REMOVE
JAMMED MASTER
IN DISPOSAL UNIT
EMPTY
DISPOSAL BOX
CLOSE SHEET
FEEDER COVER AND
PRESS ALL RESET
KEY
PAPER JAM IN
SORTER
CHECK SORTER
CLOSE SORTER’S
COVER
PAPER REMAINING
IN SORTER
REMOVE PAPER
SORTER BIN FULL
REMOVE PAPER
WRONG PAPER SIZE
SELECTION
CHANGE SELECTION
PAPER SIZE NOT
ACCEPTABLE FOR
SORTER
Master Removal Error
Displayed after the Image scanning and Master making opera-
tions are completed or in the confidential operation:
• If the Master removal sensor does not detect a removed mas-
ter while the Drum rotates from C-1 to A position, during mas-
ter removal operation.
• If the light path of the Master removal sensor is still blocked by
a removed master when the Vertical transport motor stops.
* The above checking operation is performed before master
removal only when a master exists on the drum.
Removed Master Jammed at the entrance of Master disposal box
Displayed:
• If the light path of the Master removal sensor is blocked at the
start of master-making operation.
• If the light path of the Master removal hook sensor is not blocked
at the start of master-making operation.
Empty Disposal Box
Displayed after the machine operation is finished:
• If the disposed master is detected 40 times (50 for A4-drum
models) by the Master removal sensor after the Disposal box
was emptied.
“SF3000” Bulk Sheet Feeder Error
Displayed to interrupt the machine operation:
• If the Bulk sheet feeder malfunctions.
Sorter Error - Paper jammed in Sorter
Displayed to interrupt the machine operation:
• If paper has jammed in the sorter.
Sorter Error - Sorter door (or cover) is open
Displayed to prevent the machine operation:
• If the door (or cover) of the sorter is open.
Sorter Error - Paper remains in Sorter
Displayed to prevent the machine operation:
• If the sorted sheets remain in the sort bins.
Sorter Error - Sorter bins are full
Displayed to interrupt the machine operation:
• If the sort bins are full of sorted sheets.
Sorter Error - Wrong paper size is selected
Displayed to prevent the machine operation:
• If the paper size selection on the sorter does not match with
the size of the paper loaded on the Paper feed tray.
Sorter Error - Unavailable paper size
Displayed to prevent the machine operation:
• If the size of the paper loaded on the Paper feed tray is out of
the range of paper size which can be used in the sorter.
Drum set SW OFF ⇒ ON
⇓
Push <START> key.
Master removal sensor OFF,
Master removal hook sensor
ON
Master disposal box setting
SW OFF⇒ ON, Disposal box
master sensor OFF
Turn ON bulk sheet feed cover
setting SW and, then, push
<ALL RESET> key.
Cover SW ON
Connection SW ON
Door SW ON
Remove paper and, then, turn
ON cover SW (door SW).
Remove paper and, then, turn
ON cover SW (door SW).
Remove paper and, then, turn
ON cover SW (door SW). Or,
reset paper size.
Change paper size.
