APPENDIX (I)
ADVICE DISPLAYS
GR3770 APX(I)-16
Display Details How to Cancel
ORIGINAL JAM
RESET
ORIGINAL
/3
ORIGINAL JAM
REMOVE ORIGINAL.
/2
MASTER MIS-FEED
REMOVE MASTER
ROLL THEN RE-
INSTALL
CLAMP ERROR
REMOVE MASTER
ROLL THEN RE-
INSTALL
⇓
TO RETURN OPERATION
PRESS START KEY
MASTER CUT ERROR
REMOVE DRUM
(PRINT CYLINDER) AND
CHECK MASTER
REMOVE
CUT MASTER STRIP
Original Jam at the Exit
Displayed after the master has been loaded onto the Drum:
• If the Original OUT sensor has been blocked for 1,890 pulses
after the Read pulse motor was turned on.
Oversize
Displayed after the master has been loaded onto the Drum:
• If the light path of the Original IN sensor is blocked for 14,173
pulses (FB type = 14,803) after the Read pulse motor is turned
on.
Master Mis-Feed
Displayed after the master has been loaded onto the Drum in
the master making or confidential process:
• If the Master positioning sensor has not detected master ma-
terial within 787 pulses (536 pulses in confidential process)
after the Loading pulse motor started following the master
cutting operation.
Displayed to interrupt the machine operation when the Master
loading button was pressed:
• If the Master positioning sensor has not detected master ma-
terial within 1260 pulses after the Loading pulse motor was
turned on.
• If the Master positioning sensor has not detected master ma-
terial within 787 pulses after the Loading pulse motor was
turned on following the operation of the Cutter motor and the
cut master material is removed.
Master Loading Error (onto the Drum)
Displayed to interrupt the machine operation:
• If the Master load sensor does not detect master at the Drum
C-1 position during loading of the master on the Drum.
Master Cut Malfunction
Displayed to interrupt the machine operation in master-making
and confidential process:
• If master is detected by the Master positioning sensor at Drum
A position after the cutting operation and besides it is not
detected by the Master positioning sensor at the next Drum A
position detection after the second cutting operation.
A Cut Piece of Master Remains inside the Machine
Displayed:
• If the Master positioning sensor detects master material (the
reflected light) just after the master cut operation is completed.
ADF SW OFF⇒ ON
ADF cover setting SW OFF ⇒
ON
Master making unit setting SW
OFF ⇒ ON
Master loading unit setting SW
OFF⇒ ON
⇓
Press <START> key.
Drawer connector OFF (Pull
out drum.)
Master positioning sensor
OFF
