APPENDIX (I)
ADVICE DISPLAYS
GR3770APX(I)-13
Display Details How to Cancel
T14
CALL SERVICE
T15
CALL SERVICE
T15
CALL SERVICE
T16
CALL SERVICE
T17
CALL SERVICE
REPLACE BATTERY
Clamp Error (2) 600dpi type
• In 2 seconds from turning ON of the clamp motor in clamp unit
home position return operation, the 0° or 180° angular sensor
has not detected magnet.
• In 2 seconds after the clamp motor gets ON and the 0° or 180°
angular sensor detects magnet in clamp unit home position
return operation, the clamp safety SW has not been pushed.
• In 3 seconds after reverse rotation of the clamp motor in clamp
unit home position return operation, the clamp safety SW has
not been pressed.
* While in master making operation, the master making is per-
formed to the end.
Flat Bed Read Pulse Motor Lock (300/400dpi type)
• If the Image scanner home position sensor does not detect
the Image scanner within 18898 pulses after the Flat bed
read pulse motor is activated.
• If the Image scanner ADF Shading sensor does not detect the
Image scanner within 15748 pulses after the Flat bed read
pulse motor is activated.
• If the Image scanner is not release from the Image scanner
home position sensor within 314 pulses after the Flat bed
read pulse motor is activated.
• If the Image scanner is not released from the Image scanner
ADF Shading sensor within 314 pulses after the Flat bed read
pulse motor is activated.
FB/R Pulse Motor Lock (600dpi type)
• In a fixed period of time from turning ON of the Flat bed read
pulse motor, light path of the home position sensor is not blocked.
• In a fixed period of time from turning ON of the Flat bed read
pulse motor, the home position sensor does not become light
receiving state.
• In a fixed period of time from turning ON of the Flat bed read
pulse motor, light path of the ADF shading sensor is not blocked.
• In a fixed period of time from turning ON of the Flat bed read
pulse motor, the ADF shading sensor does not become light
receiving state.
• When Image Scanner Release mode has not been executed.
• When the Image scanner fixing metal has not been removed.
Position C Sensor Malfunction
Displayed to interrupt the machine operation:
• If the Position C sensor status has not been changed from ON
to OFF (or OFF to ON) within 8 seconds from the start of the
Main Motor.
Replace Battery
Displayed to interrupt the machine operation:
• If the Battery detection signal is OFF at either of following
three cases.
<1> when the machine power is turned ON <2> when All reset
button is pressed <3> at the end of machine operation.
∗ ∗ ∗
Press <ALL RESET> key.
Press <ALL RESET> key.
Press <ALL RESET> key.
Power OFF -> ON
To Next Page
