8 - PROPULSION SYSTEM233
Sea water suction pumps
CAUTION
Do not let raw water pump run
dry! Make sure that all valves of
the raw water circuit are open.
Oil level check
Check engine oil level only approx. 20 minutes after the yacht has been
switched off.
• Pull out dipstick for oil level check.
• Wipe it with a clean, dry and lint-free cloth.
• Place it back up to retainer.
• Pull out dipstick again.
The oil level should be between the two
notches in the dipstick and must never fall
below the MIN notch. Top up oil as neces-
sary.
Ensure outmost cleanliness when han-
dling fuels, lubricants and coolants.
Waste oil drain
It is possible to drain the used oil from the propulsion engines by using a
manual pump activated by means of the relevant lever
CAUTION
Do not top up oil exceeding the MAX notch of the dipstick. If the oil level
is too high, damage to the engines may occur!
