Figure 113: Unstacked View
Operator's Manual
re
s
„.1
1
1blarC
i
,,S*F CD C
a
M iters
One-Man
Ladde
Stands
.622 BACKPACKING STRAP
ATTACHMENT INSTRUCTIONS
Stack metal components of the ladder
AS SHOWN IN
FIGURE 1A AND 1B.
Lay stabilizer with extension tube along side of stacked ladder.
Wrap the provided ladder ratchet strap around the stacked frame.
Hook the two "S"-hooks together and ratchet tight.This will se-
curely hold all ladder components together.
Attach backpacking straps (48067) on packed ladder. Fold strap
in half. Feed folded strap through foot platform mesh and around
platform frame OR around the ladder rung located directly under-
neath the foot platform. Feed the two loose ends of strap through
folded loop and pull tight forming a cinch knot.
SEE FIGURES 2A
AND 2B.
Feed the two loose ends of straps around bottom group
of ladder rungs and secure with provided tri-slide buckles.
SEE FIGURE 2C.
Secureall laddersections and stabilizer bar togetherwith your ratchetstrap.
Figure IA: Stacked View
ha
Figure 2A: Attaching the straps
Figure 26: Pulling the straps tight
Figure 2C: Attaching
straps to bottom
