RM ONE - The Rear of the Computer

2: System Description
The Rear of the Computer
Rear Cover Screws
Rear System
Exhaust Fan
Rear IO
Security Panel
Cable Run
Power Supply
Exhaust Fan
Panel
Screws
Do not place the RM One flat against a wall as this will obstruct the
rear vents and may cause the system to overheat. This may cause
the RM One to exhibit poor performance or even permanently
damage the system.
To gain access to the rear connectors remove the security panel by
first removing the two panel screws.
To gain access inside the RM One, remove all four rear cover screws
and carefully remove the back panel.
21
