DAILY LIVING
Doc No: 21906540-RSAD Rev: 02 Copyright © Roadtrek Motorhomes Inc. 2010 B-2
Picture B-P4A: Rear table leg located on the driver
side, behind the drivers seat, (SS model stored
position).
CLOVERLEAF DINING TABLE:
The cloverleaf dining table is stored beside the driver side
lounge seat, (see Picture B-P3). Remove the table leg from
the rear closet, (see Picture B-P4) and place it in the floor
base receptacle located in front of the lower galley cabinet.
Place the table top on top of table leg.
To use the table “leaves”:
1. Pivot the table into the desired position.
2. In the seated position, with one hand on the top
of the table, use the other hand to unfold the
desired leaf to the upright position.
Caution: The locking mechanisms are spring-loaded.
Watch your fingers.
To return the “leaf” to its original position, use the
following steps:
1. Hold the leaf with one hand.
2. With the other hand reach under the table and
carefully press on the center of the downward
facing part of the spring hinge.
3. Fold the leaf back into the stored position.
Caution: The cloverleaf dining table is heavy, bend
your knees while lifting.
NOTE: Due to space limitations the cloverleaf table is
replaced in the SS model with a folding table stored
above the refrigerator (Picture B-P4B).
Picture B-P3: Lower galley cabinet showing location
of cloverleaf table in RS model, (stored position).
Picture B-P4: Cloverleaf and dinette table legs
in the stored position, located in the rear passenger
side closet.
Cloverleaf
dining table
Table
legs
Picture B-P4B: Folding front table, (SS model)
