WASHROOM AND SHOWER AREA:
FRONT AND REAR WASHROOM DOORS:
Rear washroom door:
1. To open the rear washroom door loosen
the thumb screw, lift the door latch and
pull, (see Picture B-P18).
Front washroom door:
1. To open the front washroom door lift the,
(in transit) locking pin and turn the pin
towards the aisle, (see Picture B-P21).
2. Be sure to have the rear washroom door
open first.
3. Pull door open.
Washroom exhaust fan:
1. To open the washroom exhaust vent, push
up on the vent handle, (see picture B-P20).
2. To turn on the washroom exhaust vent,
turn the ON/OFF switch clockwise to the
“ON” position, (see Picture B-P20).
Picture B-P19: Inside shower door latch (RS model).
Picture B-P21: Front bathroom door, (in transit)
locking pin in the locked position.
Picture B-P20: Bathroom exhaust vent.
Picture B-P18: Washroom, (in transit) door latch (RS
model).
