SIGNAL SELECTION SWITCH:
Standard A/B Switch:
A (Button out): Antenna.
B (Button in): Cable.
AUDIO/VIDEO CABINET:
The following are found in the audio/video cabinet,
(see Picture BP42).
1. A/B signal selection switch.
2. Antenna ON/OFF switch, (Wineguard crank up).
3. Surround-Sound Home Theater system. (NOTE: The
rear vehicle speakers are wired as the HT front left and
right channels, assuming that users would be watching
movies from the front of the vehicle)
4. Audio/Video 110V AC receptacle.
5. Rear speaker mode switch
AUTOMOTIVE TIRE JACK LOCATION:
To access the tire jack use the following steps.
1. Remove the passenger side floor mat.
2. Push and turn the automotive jack compartment
securing screw 1/4 turn to the left. Remove jack
storage compartment cover, (see picture B-P43A).
3. Automotive tire jack, (stored position), (see picture
B-P43B).
DAILY LIVING
Picture B-P42: A/V cabinet.
Picture B-P41: Signal selection switch, (standard).
Picture B-P43A: Automotive jack storage
compartment cover securing screw.
1
2
5
3
4
Picture B-P43B: Automotive tire jack, (stored
position).
