Robe RoboSpot - Functions Mapping DMX Values

30
6.1 Functions Mapping
By entering the menu you can assign e󰀨ects from the list of available e󰀨ects to the jog-wheels and faders.
List of available e󰀨ect channels depends of the used moving head. The item All - releases all assigned e󰀨ects
at one go.
Note: The FollowSpot Controller does not allow to control full DMX range (0-255) of some e󰀨ects, available
DMX values for each e󰀨ect are stated in the tables below.
The item "Heigh." (Height) is not stated in tables below and serves for Multi Devices Control.
Fixture E󰀨ect Available DMX values
Robin BMFL FollowSpot
Dimmer 0-255
Iris 0-179
Focus 0-255
Zoom 0-255
L Frost 0-254
M Frost 0-254
H Frost 0-254
Color 1 0,130-189
Color 2 0,130-189
Cyan 0-255
Magenta 0-255
Yellow 0-255
CTO 0-255
Fixture E󰀨ect Available DMX values
Robin BMFL Spot
Dimmer 0-255
Iris 0-179
Focus 0-255
Zoom 0-255
L Frost 0,1-50
M Frost 0,87-136
H Frost 0,173-222
Color 1 0,130-189
Color 2 0,130-189
Cyan 0-255
Magenta 0-255
Yellow 0-255
CTO 0-255
DgW. pos 0-127
DgW. r1 0-255
DgW. r2 0-255
RGW 1 0,32-59
RGWr 1 0-255
RGW 2 0,32-59
RGWr 2 0-255
Prism 0-127
Pris r 0-255
