Robotiq Hand-E C10 Gripper Instruction Manual
CAUTION
When no tooth lock washer is present, lock screws in place using medium strength threadlocker.
Tooth lock washers provide grounding for the casing of the gripper through the mounting screws. Refer to
the Electrostatic Discharge Safety section.
INFO
The following images display the Hand-E Gripper, but the same structure applies.
Fig. 3-1: Installing Hand-E C10 on the Robot Tool Flange for CB-Series
17
