1 ROBOX DV CHARACTERISTICS
1.1 Name plate
1) ROBOX DV configuration
ES with sound hood
2) Blower size from 45 to 145
3) ROBOX DV size from 2 to 5
4) Operation
DV Vacuum operation
5) Accessories
SNT electronic monitorino unit SENTINEL
6) Execution 0001
Note : For the description of the materials see the catalog or contact ROBUSCHI.
7) Technical data
1.2 External front view
Roof panel
SENTINEL (only SNT version)
Ventilation air exit opening
Roof keykey
Vacuum gauge (standard version)
Front panel key
Label : FORBIDDEN TO OPEN THE NOISE HOOD
DURING OPERATION
Front panel
Fig. 1
1.3 External rear view
Air inlet opening
Inlet pipe
Upper rear panel
Cables glands
Discharge pipe
Lower rear panel
Fig. 2
CE
Parma
Italy
Type ES 65 / 2 DV - SNT
S/N 0405116 exec. 0001
m3/h 1000 kW 37
dp 500 n 1450
mbar RPM
(1)
(2)
(4)
(5)
(6) (7) (3)
