2 PERFORMANCE LIMITS AND WORKING CONDITIONS
2.1 Operating environment and conveyed gas
ROBOX DV is suitable to operate only in dust free environment, with no-explosive or corrosive atmosphere and to convey only atmospheric
Air or Nitrogen.
Warning : ROBOX DV is not suitable to convey explosive, toxic or dangerous gases.
Warning : The suction of liquids damages the blower.
2.2 Performance limits
Size
RPM
(mbar)
(mbar)
(°C)
(°C)
(°C)
(°C)
MAX MIN
45 5000 100 500 150 1000 50 -25 150 130 50 -25
65 4000 900 500 150 1000 50 -25 150 130 50 -25
85 3800 700 500 150 1000 50 -25 150 130 50 -25
105 3000 550 500 150 1000 50 -25 150 130 50 -25
125 2400 450 500 150 1000 50 -25 150 130 50 -25
145 2000 350 500 150 1000 50 -25 150 130 50 -25
Po Atmospheric pressure
P1 Blower inlet absolute pressure T1 Blower inlet temperature
P2 Blower outlet absolute pressure T2 Blower outlet temperature
To Atmospheric temperature -20°C < To < +45°C Installation altitude < 1000 masl (if not differently specified on page 5)
2.3 Flow adjustment
Change transmission ratio
Change the frequency supply of the motor
Use a two speed motor
Discharge excess flow and silence it
Warning : Do not use relief valve to discharge excess flow
Warning : Do not recirculate flow to ROBOX DV inlet.
Warning : Do not adjust flow by throttling inlet or outlet pipe.
2.4 Noise level
Noise level radiated from the surface of ROBOX DV is indicated at page 4 as Sound Pressure Level measured according to ISO 3476 at 1 m
distance from ROBOX DV and in free air (tolerance +/- 2 dB(A))
Warning : For high compression ratio and for high speed of rotation noise level of ROBOX DV can be higher
than 85 dB(A).
Note : The noise radiated from the piping connected to ROBOX DV can be different from the value indicated in
this manual because it depends by the piping configuration.
