1.4 Internal motor side view
Inlet pipe
Fig. 3
1.5 Internal front view
Blower RB-DV
Injection silencer
Injection port connected to the outside
V-belt guard (optional)
V-belt tension device
Label:
FORK LIFT HOISTING POINT
Label:
READ THE INSTRUCTION MANUAL
Label:
WARNING HOT SURFACE
Fig. 4
Inlet silencer
Elastic connection
Injection manifold
Electric motor
Discharge silencer
Elastic connection
