In the table
below are indicated the recommended spare parts for normal use of ROBOX DV according forecast timing.
For the spare parts of blower spare parts refer to section at page 42.
Parts Pos. Description
Operation
Start-up 2 year 5 year 10 year
ROBOX DV
SP 306 Filter element 1 2 5 10
SL 998 V-belt (set) 1 1 2 4
SL 995 - 997 Transmission pulleys 1 1 2 4
BAS 66 - 74 Elastic connectors (set) 1 1 2 4
Blower
11 A - B Gears (couple) - - - 1
16 A - B Lubricating disc (couple) - - - 1
20 Sealing chamber (set) - - - 1
23 A - B - C Oil splash disc (set) - 2 4 8
25 Sealing spacers (set) - 1 2 4
26 Nut (couple) - - 1 2
27 A Nut (RBS 125 – 145) - - 1 2
31 - 32 - 33 Bearing (set) - - 1 2
37 Shaft sleeve 1 2 4 8
43 Seal ring 1 2 4 8
45 Flexible piston rings (set) - 1 2 4
50 Gaskets (set) 1 2 4 8
63 - 63 A Compensating ring (set) - 1 2 4
75 - 76 - 77 Oil draining plugs (set) 1 2 4 8
78 Oil level plugs (set) 1 2 4 8
In case of order please quoting always Type, serial number and year of construction of ROBOX DV (these elements are indicated in front
page of this manual) and relevant position of spare part indicated in the table above.
Warning : Do not use non-original spare parts or accessories .
Note : ROBUSCHI will not be liable for any damage, breakdown, injury deriving from the use of non-original
spare parts or accessories
6.8 ROBOX DV demolition
In case of demolition of ROBOX DV verify the eventual presence of explosive, toxic or dangerous substances and dispose them in
accordance with local regulations.
Warning : Dispose the used oil in accordance with local regulations.
Warning : Dispose the filter element in accordance with local regulations.
Demolish ROBOX DV in such a way to make impossible to use again ROBOX DV as complete unit, or to use again one or several parts of
ROBOX DV.
Note : Destroy the name-plate of ROBOX DV and any other document
