Laser source specifications
Laser type
TFL (Thulium Fiber Laser)
Wavelength
1940 nm ± 20 nm
Maximum power
60 W
Pulse Energy
0.02-6J
Operating mode
Pulsed / CW
Pulse duration
Up to 15 ms
Repetition rate
1-2500Hz
Beam divergence
440 [-40] mrad ʹ 540 [+40] mrad
Beam transmission
Optical fiber system
Aiming Beam
Laser Diode, green 532nm (adjustable) < 5mW, class 3R
Exposure time
100 s
MPE
1000 W/m
2
NOHD
0.62 m
OD
2
Glasses specification
1940 D LB4
Note 1: During the lifetime of the device the laser energy values can diverge from the declared ones by a 20% maximum.
Note 2: The device is provided with internal measuring system to control the actual emission of the laser energy. The device does not require
calibration by the user.
Warning: Equipment not suitable for use in the presence of flammable mixtures.
NOTE! To prevent damage during transport or shipment of products, we recommend using the original
packaging material.
^^KZ/^
Accessory
Description
Frontal optical fiber with RFID System
(available according to customer
requirements)
Sterile single-use and reusable bare optical fibers with core
diameter from 150 up to 1000 µm.
Fiber stripper 1
Fiber stripper for 0,3-1 mm diameter
Fiber stripper 2
Fiber stripper for 0,1-0,4 mm diameter
Fiber cutter
Ceramic fiber cutter
Safety Goggles
Safety Goggles
