cobas® 4800 System
3 Hardware
Systeni Manual Instrument
Each run has test specific controls e.g.
positive/negative
control. Controls are loaded
together with the reagents onto the reagent carrier.
NOTICE
Instrument damage due to the use of inappropriate or closed tubes
Using the incorrect tube types or closed tubes en sample carriers can damage the
instrument
Use only specified tube types for sample carriers.
Do not
use
closed tubes en sample carriers. Always open
tubes
on all sample
carriers.
Barcode dirnensions
c
B
c
U
.
EL1
A
A Label length: max. 80 mm
B Code Ienght: max. 74 mm
C
Quiet zone: min.
3
mm
D Label width: min. 12 mm
E Code width: min. 12 mm
F Distance from code to label edge: max. 1 mm
Fi9ure 3-15 Barcode dimensions
Positioning
barcode labels on
The
barcode must
fit within a range of between 20 mm
and
100
mm from the bottom
sample tubes of the tube.
100 mm
2OmmL
Figure 3—16 Fixing barcodes to sample tubes
Make sure the bars are perpendicular to the tube.
For additional details about barcode types and specifications,
see
Barcode reader
(p.
63)
Positioning barcode labels on
containers
Figure 3—17 Fixing barcodes to containers
Roche Diagnostics
System Manual
. Version
1.0 51
